VertiFlex All Glass
Vertiflex All-Glass
Automatic & Frameless Guillotine Glazing System
VertiFlex is a remote-controlled, motorized, chained, movable handrail glazing system. This guillotine system has been developed the full panoramic view as its designed with no frames.
Why to Choose
- High Quality
- User Friendly
- Safety Tested & Approved
- Smart & Fast Construction
- Available in standard colors
- Various options & accessories
- Incl. 5 years of motor warranty
Uninterrupted View
Guillotine System without Frame
VertiFlex All Glass has been developed to keep the uninterrupted view as the system has no frames. Its well-thought design provides the system's desirability and extensive and differentiated usage areas.
Vertiflex All Glass can be applied to glazing applications designed to reach a full panoramic view. Especially, observatories, terraces, stadium,/loge covering are preferable.
CONTACT US NOW!
SHOW TECHNICAL INFORMATION
Maximum Panel Sizes
In the system, there are four balancing wheels. A system can be made up of four panels—panel sizes are 4 meters in height, 3 meters in width.
Chain Conveyor System Designed for Heavy Lift
Each panel, produced using double steel chains, has a 400 kg lifting capacity and 8.51 mm - 14.75 mm chain lock thickness.
Silent & Perpetual
Motion
Albert Genau's patented G-Motion system; guarantees a quiet and comfortable movement. The balancing wheels provide smooth movement. In addition, the sealed motor caps have sound insulation.
Hidden Junction
Details
All vertical junctions are hidden. A specially designed cap profile closes the side panel channels aesthetically.
Easy Installation
& Fast Service
It's easy to montage and fast service thanks to the combination of partial side profiles, adjustable bottom profile and the freestanding motor mechanism.
Think Green
This system is environmentally friendly as using minimal profiles lets maximum sunlight in and minimises energy loss.
HIDE TECHNICAL INFORMATION
Last year, I've started to use this system on my terrace. As it is the summer house, isolation was not my main concern. The problem was cleaning because of the dust and leaves. I had to get that one done. So, I like it as I also preserve my terrace view! Many thanks!
Sarah Fisher
I have this one on my restaurant. As it's an automatic system, it's easy to move it regarding weather conditions. It's been a kind of adding place. Also, the cleaning of the outdoor has been a bit eased. Thanks!
Robert Hill
